SKF TMHC 110E Hydraulic Bearing Puller

SKF TMHC 110E Hydraulic Bearing Puller is a tool which is used to remove components such as gears, bearings and pulleys from a shaft or a recess. It securely grips the component with specially designed jaws before driving it off the shaft. SKF TMHC 110E Hydraulic Bearing Puller is used in every industry for safely and effectively dismounting bearings.

Technical Specifications

• Make: SKF
• Type: TMHC 110E
• Maximum stroke: 80 mm (3.1 in)
• Nominal working force: 100 kN (11.2 US ton force)
• Weight: 13,5 kg (29.8 lb)
• Cycle life hydraulic cylinder: Minimum 5000 cycles up to 100 kN (11.2 US ton force)
• Threading hydraulic cylinder: UN 11/2 inch x 16 tpi
• Safety valve setting hydraulic cylinder: 105 kN (11.8 US ton force)
• Carrying case dimensions: 580 x 410 x 70 mm (23 x 16 x 2.8 in)
• Contents: 1 x arm-assembly stand  3 x arms, set 1 (TMHP10E-9) 3 x arms,  set 2 (TMHP10E-10)1 x separator set 1 x beam  2 x main rods 2 x extension rods, 125 mm (4.9 in) 1 x hydraulic spindle TMHS 100 2 x extension pieces for hydraulic spindle; 50, 100 mm (2.0, 3.9 in)1 x nosepiece with centre point for hydraulic spindle
• Condition: New Surplus
